CAD ஆடியோ D90 கையடக்க டைனமிக் மைக்ரோஃபோன் பயனர் கையேடு

1. அறிமுகம் மற்றும் முடிந்துவிட்டதுview

The CAD Audio D90 is a premium supercardioid dynamic handheld microphone designed for live vocal performance. It features a Trueflex diaphragm and PowerGap high-gauss neodymium magnets, delivering a strong and articulate signal. Its durable, all-metal construction ensures reliability for stagஇ பயன்பாடு.

Image 1.1: The CAD Audio D90 Handheld Dynamic Microphone.

முக்கிய அம்சங்கள்:

• Trueflex Diaphragm: Provides articulate response for clear vocal reproduction.
• Powerful Neodymium Magnet: Ensures a hot signal output.
• சூப்பர் கார்டியோயிட் துருவ வடிவம்: Offers excellent off-axis rejection, reducing feedback and isolating the sound source.
• Durable All-Metal Construction: Built to withstand the rigors of live performance.
• Smooth and Articulate Lead Vocal Performance: Engineered for optimal vocal clarity.

Image 1.2: Illustrates the professional sound features of the CAD Audio D90 microphone, highlighting articulate clarity and a powerful signal.

2. பெட்டியில் என்ன இருக்கிறது

Upon opening your CAD Audio D90 package, you should find the following items:

• CAD ஆடியோ D90 கையடக்க டைனமிக் மைக்ரோஃபோன்
• Hard-sided road case (for protection and transport)
• Microphone clip (for mounting on a stand)

Image 2.1: Contents of the CAD Audio D90 package, including the microphone, mic clip, and carrying pouch.

3 அமைவு

Follow these steps to set up your CAD Audio D90 microphone for use:

1. மைக்ரோஃபோன் கிளிப்பை இணைக்கவும்: Secure the included microphone clip to a standard microphone stand. Ensure it is tightened sufficiently to hold the microphone firmly.
2. மைக்ரோஃபோனைச் செருகவும்: Gently insert the CAD Audio D90 microphone into the microphone clip. Adjust the angle as needed for optimal positioning.
3. XLR கேபிளை இணைக்கவும்: Connect a standard 3-pin XLR cable to the microphone's output connector at the base. The D90 is a passive dynamic microphone and does not require phantom power.
4. ஆடியோ சிஸ்டத்துடன் இணைக்கவும்: Connect the other end of the XLR cable to an input on your mixer, audio interface, or amplifier. Ensure the input gain is set to a low level before powering on your audio system.

Image 3.1: The CAD Audio D90 microphone securely mounted on a stand, ready for connection.

4. இயக்க வழிமுறைகள்

To achieve the best performance from your CAD Audio D90 microphone, consider the following operational guidelines:

Microphone Technique:

• அருகாமை விளைவு: The D90 exhibits a proximity effect, meaning bass response increases as the microphone is moved closer to the sound source. Experiment with distance to achieve desired tonal characteristics.
• On-Axis Placement: For optimal clarity and frequency response, position the microphone directly in front of the sound source (on-axis).
• Off-Axis Rejection: As a supercardioid microphone, the D90 is highly directional. Point the microphone away from unwanted sound sources (e.g., stage monitors, instruments) to minimize bleed and feedback.

கெயின் எஸ்taging:

• Start with the input gain on your mixer or interface at its lowest setting.
• Gradually increase the gain while speaking or singing into the microphone at your typical performance volume.
• Adjust the gain until the signal is strong without clipping or distortion. Aim for a healthy signal level that allows for headroom.

Image 4.1: A performer utilizing the CAD Audio D90 microphone on stage, demonstrating typical usage.

5. பராமரிப்பு

Proper maintenance will extend the life and performance of your CAD Audio D90 microphone:

• சுத்தம்: Regularly wipe the microphone body with a soft, dry cloth. For the grille, use a soft brush to remove any debris. Avoid using liquid cleaners directly on the microphone.
• சேமிப்பு: When not in use, store the microphone in its included hard-sided road case or a protective pouch to prevent dust accumulation and physical damage.
• ஈரப்பதத்தைத் தவிர்க்கவும்: Keep the microphone away from moisture and extreme temperatures.
• கவனத்துடன் கையாளவும்: While durable, avoid dropping or subjecting the microphone to harsh impacts.

6. சரிசெய்தல்

If you encounter issues with your CAD Audio D90 microphone, refer to the following common problems and solutions:

7. விவரக்குறிப்புகள்

Detailed technical specifications for the CAD Audio D90 Handheld Dynamic Microphone:

Image 7.1: Visual representation of key specifications for the CAD Audio D90 microphone.

8. உத்தரவாதம் மற்றும் ஆதரவு

For warranty information, technical support, or service inquiries regarding your CAD Audio D90 microphone, please refer to the official CAD Audio webதளம் அல்லது அவர்களின் வாடிக்கையாளர் சேவைத் துறையைத் தொடர்புகொள்ளவும்.

ஆன்லைன் ஆதரவு: பார்வையிடவும் CAD Audio Store on Amazon or the official CAD Audio website for FAQs, product registration, and contact details.

எந்தவொரு உத்தரவாதக் கோரிக்கைகளுக்கும் உங்கள் கொள்முதல் ஆதாரத்தை வைத்திருங்கள்.
