InfinityPro X Series Interactive Touch Display Panel User Manual

அறிமுகம்

This manual provides essential information for the setup, operation, and maintenance of your InfinityPro X Series Interactive Touch Display Panel. Designed for collaborative environments, this display offers advanced features for presentations, meetings, and interactive learning. Please read this manual thoroughly before using the product to ensure optimal performance and safety.

படம்: முன்பக்கம் view of the InfinityPro X Series Interactive Touch Display Panel, showcasing its sleek design and vibrant screen.

1 அமைவு

1.1 பேக்கிங் மற்றும் ஆய்வு

Carefully remove the display panel from its packaging. Inspect all components for any signs of damage. Retain the packaging for future transport or storage.

1.2 நிறுவல்

The InfinityPro X Series display can be installed using a compatible wall mount or a mobile stand (sold separately). Ensure the mounting solution is appropriate for the display's size and weight. Follow the instructions provided with your chosen mounting hardware for secure installation.

1.3 இணைக்கும் சக்தி

Connect the power cable to the display's power input and then to a grounded electrical outlet. Press the power button to turn on the display.

1.4 ஆரம்ப கட்டமைப்பு

Upon first power-on, the display will guide you through initial setup steps, including language selection, network connection (Wi-Fi), and basic system settings.

Image: Diagram highlighting various ports and features on the InfinityPro X Series display, including Type-C, USB, PC-USB, Touch, HDMI, and built-in speakers.

2. இயக்க வழிமுறைகள்

2.1 அடிப்படை வழிசெலுத்தல்

The display runs on Android 12, providing a user-friendly interface. Navigate using touch gestures similar to a tablet or smartphone. The included stylus pen enhances precision for interactive tasks.

2.2 ஊடாடும் ஒயிட்போர்டு

Access the advanced interactive whiteboard application from the main menu. This feature allows users to:

• Share content directly on the board.
• Convert handwritten shapes to text.
• Annotate directly within various file வகைகள்.
• Utilize multi-touch capabilities for up to 40 points of touch.

Image: A woman presenting a 'Tower plan' on the InfinityPro X Series interactive whiteboard, demonstrating its use in a meeting setting.

2.3 Wireless Screen Sharing

The display supports wireless screen sharing, allowing you to project content from mobile phones, tablets, notebooks, and desktops without cable clutter. Follow the on-screen instructions within the sharing application to connect your devices.

Image: An illustration showing various devices (smartphone, tablet, laptop, desktop) wirelessly casting their screens to the InfinityPro X Series display, highlighting multi-platform compatibility.

2.4 Multitasking Capability

The InfinityPro X Series allows users to open multiple applications simultaneously, including a picture-in-picture mode for enhanced productivity. This feature facilitates seamless switching and interaction between different tasks.

2.5 User Management and App Lock

The display includes enhanced user management features, allowing administrators to create user accounts with specific restrictions and permissions. Additionally, the App Lock function provides security by preventing unauthorized access to selected applications.

Image: A screenshot of the system settings interface, showing options for 'System security', 'Lock screen with USB', 'USB permissions', 'Channel permission', 'APP Lock', and 'FILE MANAGER INSTALL Lock'.

2.6 இணைப்பு

The display offers comprehensive connectivity options:

• வயர்லெஸ்: Built-in Wi-Fi (6G/6G) and Bluetooth 5.0 for seamless network and peripheral connections.
• கம்பி: Multiple USB 3.0 ports, HDMI, VGA, and an OPS (Open Pluggable Specification) slot for an optional slot-in PC.

3. பராமரிப்பு

3.1 காட்சியை சுத்தம் செய்தல்

To clean the screen, power off the display and gently wipe it with a soft, lint-free cloth. For stubborn marks, use a screen-cleaning solution specifically designed for electronic displays. Avoid abrasive cleaners or solvents.

3.2 மென்பொருள் புதுப்பிப்புகள்

The InfinityPro X Series supports Over-the-Air (OTA) firmware updates. Ensure your display is connected to the internet to receive and install the latest software versions, which provide performance enhancements and new features. Check for updates periodically in the system settings.

4. சரிசெய்தல்

4.1 சக்தி இல்லை

• பவர் கேபிள் டிஸ்ப்ளே மற்றும் வேலை செய்யும் மின் கடையுடன் பாதுகாப்பாக இணைக்கப்பட்டுள்ளதா என்பதை உறுதிப்படுத்தவும்.
• மற்றொரு சாதனத்தை இணைப்பதன் மூலம் மின் நிலையம் செயல்படுகிறதா என்பதை சரிபார்க்கவும்.

4.2 திரையில் படம் இல்லை

• காட்சி இயக்கப்பட்டுள்ளதா எனச் சரிபார்க்கவும்.
• If using an external source (e.g., PC via HDMI), ensure the source device is on and the correct input is selected on the display.

4.3 Touch Function Not Responding

• திரை சுத்தமாகவும், தடைகள் இல்லாமல் இருப்பதையும் உறுதி செய்யவும்.
• காட்சியை மறுதொடக்கம் செய்யுங்கள்.
• If connected to an external PC, ensure the USB touch cable is properly connected.

4.4 வயர்லெஸ் இணைப்பு சிக்கல்கள்

• Verify that Wi-Fi or Bluetooth is enabled in the system settings.
• Check your network router or access point for proper operation.
• Ensure the display is within range of the wireless signal.

5. விவரக்குறிப்புகள்

Image: A side-by-side comparison illustrating the superior clarity and detail of a 4K Ultra HD display compared to a normal display.

6. உத்தரவாதம் மற்றும் ஆதரவு

For warranty information and technical support, please refer to the documentation included with your purchase or visit the official InfinityPro website. If you encounter issues not covered in this manual, please contact InfinityPro customer service for assistance.
